EN 14470-1 & EN1363-1 TESTED AND CERTIFIED. OSHA AND NFPA COMPLIANT 90-MIN APPROVED LARGE DOUBLE DOOR LITHIUM-ION CABINET

COMPLIANCE
Complies with level 2 of standard EN 16121+A1 (opening/closing 80000 cycles and placement of the load defined by the manufacturer on the shelves).
Proven fire resistance of 105 minutes, according to the ISO 834 curve as per the EN 14470-1 standard
Standardized warning labels in accordance to ISO 3864 and ISO 7010, as well as the European directive 92/58/EEC.

CONTRUCTIONS
Steel construction and double thermal insulation triple wall.
Outer walls in 12/10th steel and white RAL 9010 epoxy painting.
Thermal insulation panels limiting thermal bridges.
Melamine interior panels.

EQUIPMENT
Thermodilating door seals.
Doors with automatic closing.
Perforated shelves with a load capacity of 250Lbs.
Key closing.
Ventilation holes with ventilation outlet Ø 4 inches for HVAC or ventilation box connection.
Ventilation ducts with hot-melt system to isolate the contents of the cabinet in case of fire.
Fixing point for Grounding Connectors.
Extremely robust construction with scratch -proof paints

OPTIONAL ACCESSORIES
Control box with automatic alarm, visual and audible alarm, smoke detector, and fire extinguisher activation.
Fire extinguisher with automatic thermal bulb trigger (thermal bulb if control box option is not included).
Electrical outlets system with fire-resistant cable passage.

VENTILATION
All cabinet models have ventilation holes, allowing them to be connected to a ventilation system. Forced ventilation is strongly recommended to prevent internal heat build-up or stagnation of vapors in the event of electrolyte liquid leakage. This can be connected either to an external outlet or to a ventilation or filter box.
